1
名称 Description
全电动托盘堆垛车

2
型号 Model
TB10

-16
TB10

-25
TB10

-30
TB10

-35
TB15

-25
TB15

-30
TB20

-16

3
Z大起升重量Kg Load capacity
1000
1000
1000
1000
1500
1500
2000

4
载荷中心mm Load center
500
500
500
500
500
500
500

5
Z大起升高度mm Max. lifting height
1600
2500
3000
3500
2500
3000
1600

6
自由起升高度mm Free lift
0

7
轮胎配置 Wheel type
聚胺脂实心胎 Polyurethane solid tire

8
踏板长mm Pedal length
500
500
500
500
500
500
500

9
货叉尺寸（LxW）mm Fork size
1150*190

10
货叉外宽(固定的) mm Width of forks(aptotic)
680
680
680
680
680
680
680

11
全长（踏板收起时）mm Overall length
2023
2023
2023
2023
2023
2023
2023

12
全宽mm Overall width
850
850
850
850
850
850
850

13
门架闭合时高度mm

Overall height mast closed
2080
1795
2045
2295
1795
2040
2080

14
货叉起升时Z大高度（含货叉架）mm

Overall height fork raised(with backrest)
2080
2970
3410
3910
2970
3220
2080

15
转弯半径（踏板收起）mm

Outside turning radius
1720
1720
1720
1720
1720
1720
1720

16
前轮至叉端距mm Front wheel to fork tip
330
330
330
330
330
330
330

17
Z小堆垛通道宽度（1000*1000托盘）mm

踏板收起时Min. intersecting aisle
2450
2450
2450
2450
2450
2450
2450

18
Z大行驶速度Km/h Max. walking speeds
4.0/5.8
4.0/5.8

19
爬坡能力% Grade abitity
8
8
8
8
8
8
8

20
总重Kg Total weight( with battery)
~880
~935
~950
~975
~940
~950
~905

21
驱动轮mm Driving wheel
Φ215*75

22
前轮mm Front wheel
Φ80*70

23
平衡轮mm Balance wheel
Φ150*50

24
蓄电池 电压/容量V/Ah Battery
24/210

25
充电机 V/A Charger
24/30

26
驱动马达Kw Driving motor
1.2
1.2
1.2
1.2
1.2
1.2
1.2

27
起升马达Kw Lifting motor
2.0
2.0
2.0
2.0
2.0
2.0
2.0



● 适用于单面托盘。Single face pallet.

● Z大提升高度4500mm。Max lifting height:4500mm

● 选配AC交流驱动电机，进口蓄电池，护栏。OPTIONS: AC motor, Arm rest.
