Fuel type(燃料类型)
柴油

Mast type(标准门架)
Telescopic boom(伸缩臂门架)

Capacity A(额定载荷 A)
4500 kg (9,920.80 lb)

@ Lift height A
500 mm (19.69 in)

Special feature 1
4 telescopic stabilizers,

Special feature 2
total and continuous rotation

Drawbar pull (max.)(Z大牵引力)
10880 kg

Travel speed forward, no load(行驶速度,空载)
25 kph (15.53 mph)

Engine, make(发动机制造商)
Perkins

Engine, model(发动机型号)
1004.40TW

Rated power(额定功率)
123 HP

Transmission, type(传动类型)
Hydrostatic(静压)

Gears forward(前进齿轮数量)
2

Gears reverse(后退齿轮数量)
2

Max. lift height(Z大提升高度)
20.6 m (22.53 yards)

Max. forward reach
17.6 m (19.25 yards)

Lowered height(缩回高度)
3025 mm (119.09 in)

Machine length(车体长度)
6490 mm (255.51 in)

Machine width(车体宽度)
2.43 m (2.66 yards)

Machine weight (no load)(自重,空载)
14700 kg (32,407.96 lb)

Gross weight (with load)(总重,满载)
19200 kg (42,328.76 lb)


Wheel number(轮胎数量)
4

Wheels driven(驱动轮数量)
4

Tyres, type(轮胎类型)
Pneumatic(充气轮胎)

Tyre size(轮胎尺寸), front(前轮尺寸)
18-22.5

Tyre size(轮胎尺寸), rear(后轮尺寸)
18-22.5

Brakes, type (service)(刹车类型)
disc
