Fuel type(燃料类型)
汽油/液化气

Mast type(标准门架)
2级门架/高视野

Capacity A(额定载荷 A)
3000 kg (6,613.87 lb)

Load Centre (中心) A(载荷中心A)
500 mm (19.69 in)

Drawbar pull (max.)(Z大牵引力)
2000 kg

Lift speed, with load(提升速度,满载)
500 mm / sec. (19.69 in/sec)

Lift speed, no load(提升速度,空载)
600 mm / sec. (23.62 in/sec)

Travel speed forward, with load(行驶速度,满载)
17.1 kph (10.63 mph)

Travel speed forward, no load(行驶速度,空载)
18.0 kph (11.18 mph)

Engine, model(发动机型号)
G430

Rated power(额定功率)
43.4 KW

@ rpm(发动机额定转速)
2200

Transmission, type(传动类型)
Powershift

Gears forward(前进齿轮数量)
1

Gears reverse(后退齿轮数量)
1

Max. lift height(Z大提升高度)
3230 mm (127.17 in)

Free lift(自由提升高度)
152 mm (5.98 in)

Lowered height(缩回高度)
2150 mm (84.65 in)

Machine length(车体长度)
2280 mm (89.76 in)

Machine width(车体宽度)
1110

Machine weight (no load)(自重,空载)
4140 kg (9,127.14 lb)

Wheel number(轮胎数量)
4

Wheels driven(驱动轮数量)
2

Tyres, type(轮胎类型)
Cushion(实心轮胎)

Brakes, type (service)(刹车类型)
Oil Cooled Disc Brake
